RIDDHI PHARMA MACHINERY LTD.

MACHINE TECHNICAL SPECIFICATION

PVC Base Film Width Max.                                210 mm

PVC Film Thickness Max.                                  0.2- 0.4 mm

PVC Reel Dia. Max.                                          440 mm

Aluminum Foil Width Max.                                 206 mm

Aluminum Foil Thickness Max.                           0.02-0.03 mm

Aluminum Foil Dia. Max.                                   210 mm

Total Forming Area.                                         MAX 210 x 102 mm. MIN 210 x 25 mm

Pack Length.                                                  200 mm

Pack Width.                                                   100 mm

Forming Depth.                                              16 mm

Out Put.                                                        240 Packs / Min (2400 Blisters / Min)

Overall Dimensions (Approx.)                            L: 3100mm x W: 1100mm x H: 2000 mm.

Net Weight (Approx.)                                       1150 kgs.

Utilities Requirement:

Compressed Air        :  7 CFM Dry air at a Pressure of 8 Kg/Cm2

Water Cooler           :  160 Liters / Hr Temperature 20 + 2 Degree Centigrade

Electrical Power        :  7.5 KW, 400 VAC + 10%, 3 Phase + N + E

Earthing Cable          :  Copper, 2.5 mm2 (Minimum)
